Melbon Galaxy Full HD Free to Air WiFi Set Top Box

Main Features:

DVB-S & DVB-S2 Compliant.

MPEG-2 MP@HL video decoder

AVC/H.264 HP@L4.1 video decoder

MPEG4 ASP supported

Fully compliant with HDMI1.3 specification

Video Resolution: 1080p,1080i,720p,720i,576p,576i

USB2.0 for PVR, Time-shift and timer.

Support MP3/ WMA, AVI/MKV/MP4/, BMP/JPG playback.

Blind scan, Sat scan, TP scan, NIT scan

Max 2000 TP and 4000 Programs restore.

DiSEqc1.0/DiSEqc1.2/ DiSEqc1.3( USALS).

Support 7-day EPG, Teletext and Subtitle.

Parental lock, Channel Edit, Favor edit.

OTA, RS232, USB upgrade

Technical Specification:

Chipset and Memory:

Processor : ALI M3510C

Flash:4MB\8MB serial flash

DDR: DDRII 800 64MB

TUNER:M3031

Power

Input: DC12V 1.5A

Operating:15W MAX

Interface:

ANT IN x1

LOOPOUT x1 (optional)

AV: RCA x4

HDMI 1.3x1

USB2.0 port: x2 (optional)

RS232 4Pin

Video Decoding

Compliant with: MPEG-4 part10 /MPEG-2 ISO/IEC 13818,

MPEG-4 Simple/Main/Advanced Profile@Level3(10Mbps),

MPEG-2 Main Profile@ Main Level(15 Mbps)

H.264 MP@L3(10Mbps),H.264 HP@L4.1 (25Mbps)

Video Resolution: 1080p,1080i,720p,720i,576p,576i

Audio Decoding

Compliant with: MPEG-1/2/3, AC-3, HE AAC (optional)

Support Dolby down-mixed 2 channel (optional)

Accessories

Remote Control

AV Cable

Adaptor

User Manual

This Box can also use with the C-Band Dish antenna for free-to-air TV channels.

Here you can check the DD Freedish TV Channels list which you can get by using this set-top box (antenna Installation is required). This box also suitable to receive DD Free dish  MPEG-4 / HD channels.
